Among Lauderdale Lakes’s oldest pools — those built in the 1960s and early 1970s — cracking of the pool shell is a common finding that ranges from cosmetically unpleasant but structurally insignificant to actively leaking and requiring immediate repair. Distinguishing between these categories determines whether a homeowner faces a $2,000-$4,000 repair project or a cosmetic plaster resurfacing that can be scheduled at the next renovation cycle.
At Pool Service Fort Lauderdale, we service pools throughout Lauderdale Lakes and help homeowners evaluate crack conditions that appear during routine maintenance visits. This guide covers how to distinguish surface from structural cracks and what repair options exist for each.
Surface Crazing vs. Structural Cracks — How to Tell the Difference
Surface Crazing (Map Cracking)
Surface crazing — fine, spider-web-pattern cracks across the plaster finish — is normal at or near end-of-life for pool plaster. These cracks are confined to the plaster layer only, not penetrating the underlying gunite shell. They look alarming but are not structurally significant.
Surface crazing results from the calcium carbonate matrix of aging plaster contracting as it loses moisture and chemical stability over time. It typically appears on older plaster surfaces and is one indicator (along with roughness and staining) that the surface is approaching end-of-life. Resurfacing addresses surface crazing — no structural repair is needed first if the cracks are confirmed to be surface-only.
Visual identification: crazing cracks follow irregular patterns, typically don’t follow a single line for more than a few inches, and are very fine (hairline width). Running a fingernail across them reveals they don’t penetrate significantly below the surface texture.
Structural Cracks
Structural cracks penetrate through the plaster finish into or through the gunite shell beneath. They often follow a longer linear pattern (along stress lines in the shell), may be wider than crazing (visible gap rather than hairline), and may have visible displacement (one side of the crack slightly elevated relative to the other).
Structural cracks create pathways for water loss and in severe cases allow soil infiltration — the direction of flow can go either way, depending on water table conditions. A pool that maintains water level consistently is not leaking significantly regardless of visible crack appearance; a pool that shows ongoing water loss beyond normal evaporation needs leak investigation.
The Bucket Test — Confirming Whether Cracks Are Leaking
The bucket test is the standard homeowner method for distinguishing leaks from evaporation:
- Fill a 5-gallon bucket with pool water and place it on the top pool step (fully in the water, so both the bucket and pool surface are at the same temperature)
- Mark the water level in the bucket and the pool water level on the bucket’s exterior
- Turn off the pool pump and auto-fill valve for 24 hours (do not add water)
- After 24 hours, compare: if the pool water level dropped more than the bucket water level, the difference represents structural water loss beyond evaporation
Normal evaporation in Lauderdale Lakes during summer: approximately 1/8 to 1/4 inch per day. If the pool water drops more than 1/4 inch per day beyond the bucket’s evaporation, a structural leak is present and professional leak detection is warranted.
Structural Crack Repair Options for Lauderdale Lakes Pools
Hydraulic Cement Injection
For cracks that are actively leaking, hydraulic cement (a fast-setting cement compound that expands to fill crack voids) can be chiseled and packed into the crack from inside the drained pool. This is the standard approach for linear cracks in the shell body. Hydraulic cement repair is durable but doesn’t flex — if the shell is moving (settling, thermal cycling), the repair may re-open over time.
Epoxy Injection
Two-part epoxy injected under pressure into crack ports drilled along the crack line bonds the crack faces and provides a flexible, waterproof repair that accommodates minor thermal movement better than cement-based approaches. Epoxy injection is preferred for actively moving cracks or locations where the shell may continue to settle slightly.
Structural Gunite Application
For major structural damage — multiple cracks, significant delamination of the plaster from the shell, or areas where the gunite shell has spalled — localized gunite application (by a licensed shotcrete contractor) rebuilds the damaged shell area before resurfacing proceeds. This is the most expensive repair option but provides the most durable structural restoration.
What Crack Repair Costs in Lauderdale Lakes
Hydraulic cement or epoxy injection repair for a standard residential pool crack: $400-$1,500 depending on crack length and access. Major structural repairs requiring gunite application: $2,000-$6,000+. These costs are in addition to the resurfacing that typically follows structural crack repair on an aging pool surface.
Pool Service Fort Lauderdale can coordinate crack assessment, leak detection, and repair referrals for Lauderdale Lakes pool owners with aging gunite shells. Call (954) 501-2754 or visit our Lauderdale Lakes pool service page. Full coverage at poolservicefortlauderdale.us.
Frequently Asked Questions
{
“@context”: “https://schema.org”,
“@type”: “FAQPage”,
“mainEntity”: [
{
“@type”: “Question”,
“name”: “How do I know if the cracks in my Lauderdale Lakes pool are structural or just surface?”,
“acceptedAnswer”: {
“@type”: “Answer”,
“text”: “Surface crazing is fine spider-web pattern cracks in the plaster only — cosmetic and normal at end-of-life. Structural cracks are wider, longer linear cracks that may show displacement (one side elevated) and penetrate into the gunite shell. Do the bucket test: if the pool loses more water than the bucket over 24 hours, you have a structural leak requiring repair.”
}
},
{
“@type”: “Question”,
“name”: “How do I do the bucket test to check for pool leaks in Lauderdale Lakes?”,
“acceptedAnswer”: {
“@type”: “Answer”,
“text”: “Fill a 5-gallon bucket with pool water and place it on the top step (in the water). Mark levels inside and outside. Turn off pump and auto-fill for 24 hours. If the pool water level drops more than the bucket water level, the difference is a structural leak. Normal Lauderdale Lakes evaporation is about 1/8 to 1/4 inch per day.”
}
},
{
“@type”: “Question”,
“name”: “Can I resurface my Lauderdale Lakes pool before repairing structural cracks?”,
“acceptedAnswer”: {
“@type”: “Answer”,
“text”: “No. Structural cracks must be repaired before resurfacing. New plaster applied over an unrepaired structural crack will crack again as water movement through the crack continues. The repair sequence is always: structural repair first, then resurfacing. Surface crazing only (no structural leak confirmed) can be addressed by resurfacing alone.”
}
},
{
“@type”: “Question”,
“name”: “How much does crack repair cost on an older Lauderdale Lakes pool?”,
“acceptedAnswer”: {
“@type”: “Answer”,
“text”: “Standard hydraulic cement or epoxy injection repair: $400-$1,500 depending on crack length and access. Major structural repairs requiring gunite application: $2,000-$6,000+. Crack repair costs are in addition to resurfacing ($4,500-$12,000) when both are needed, which is common for 40-50 year old Lauderdale Lakes pools.”
}
},
{
“@type”: “Question”,
“name”: “What causes structural cracks in old Lauderdale Lakes pools?”,
“acceptedAnswer”: {
“@type”: “Answer”,
“text”: “Soil movement (settling, shrink-swell from South Florida’s sandy soils and seasonal moisture changes), thermal expansion and contraction of the concrete shell, tree root pressure, and the cumulative stress of 50+ years of hydrostatic pressure. Some structural cracking in a 50-year-old gunite pool is not unusual and doesn’t indicate the pool needs to be replaced — it typically indicates it needs targeted repair before the next resurfacing cycle.”
}
}
]
}
How to tell surface vs structural cracks? Surface crazing is fine spider-web patterns in plaster only. Structural cracks are wider, linear, may show displacement. Bucket test confirms whether leaking.
How to do the bucket test? Bucket on top step, mark levels, turn off pump and auto-fill for 24 hours, compare. More pool loss than bucket loss = structural leak.
Can I resurface before repairing cracks? No — structural cracks must be repaired first. New plaster over unrepaired cracks will re-crack.
What does crack repair cost? $400-$1,500 for epoxy/cement injection. $2,000-$6,000+ for gunite structural repair. Both in addition to subsequent resurfacing costs.
What causes structural cracks in old pools? Soil movement, thermal cycling, tree roots, 50+ years of hydrostatic pressure. Targeted repair rather than pool replacement is the typical response.
